01The approach
Passenger three-wheeler
GOEEN NJA-8 electric passenger three-wheeler
Load capacity
Passengers and cargo counted together. The figure an ordinary working day actually runs on.
Range
A BLDC mid motor, lithium or lead, and 4:30 hr back to full while the street is asleep.
Ground clearance
Telescopic at the front, spring adjustable at the rear, for streets nobody ever resurfaced.
Boot space
Two lockable decks, tubeless 3.00 - 8 tyres and drum brakes at both ends.
02The figures
Everything below is quoted from the NJA-8 specification sheet, unrounded. The rest of the page is these five figures shown rather than stated.
- Load capacity
- 250Kg
- Range
- 70km
- Boot space
- 51L
- Ground clearance
- 140mm
- Overall length
- 1950mm
Passengers and cargo together
On a single charge
Across two lockable decks
Minimum, unladen
690 mm across the shoulders
Figures as supplied on the NJA-8 specification sheet. Range and charging time vary with load, terrain, riding style and battery condition.
03Walkaround
Studio · one full turn
A full turn of the NJA-8
01Front three-quarter
Lit at both ends.
LED Projector
02Nose
690 mm across the shoulders.
690 mm
03Deck
Two lockable decks under the seats.
51 L
04Rear
A carrier over the rear axle.
250 Kg
04The envelope
Narrow enough for the lanes the work is actually in, and 1950 mm end to end. Drawn here to scale — side and front elevation, on a 100 mm grid.
- Overall length
- 1950 mm
- Overall width
- 690 mm
- Overall height
- 1190 mm
- Seat height
- 760 mm
- Seat length
- 600 mm
- Min. ground clearance
- 140 mm
Figures as supplied on the NJA-8 specification sheet. Range and charging time vary with load, terrain, riding style and battery condition.
05Charging
One vehicle, one port, two chemistries. Drawn against the same twelve-hour face: the difference between plugging in after dinner and plugging in after work.
- Battery type
- Lithium / Lead
- Motor
- BLDC Mid Motor
- Range
- 70 km
Lithium
Ready before the street is awake.
Figures as supplied on the NJA-8 specification sheet. Range and charging time vary with load, terrain, riding style and battery condition.
06Closer look
Whole vehicle
1950 mm end to end
Long enough for two passenger benches, short enough to turn where the work is.
Deck
760 mm seat height
A step up, not a climb — 600 mm of seat length per bench.
Rear axle
Tubeless 3.00 - 8
Drum brakes front and rear, spring adjustable shock over the axle.
07Exploded
Factory diagram
The NJA-8, taken apart
The whole machine
Held apart.
The factory's own exploded drawing. Everything the NJA-8 is made of, in the order it goes together.
Front end
Telescopic, and tubeless.
A telescopic shock absorber over a tubeless 3.00 - 8 front wheel, with a drum brake inside it.
- Telescopic shock absorber
- 3.00 - 8 tubeless
Power
Lithium or lead, one bay.
The pack drops into the frame from underneath and the controller sits below it. A BLDC mid motor, 70 km, and 4:30 hr back to full on lithium.
- Battery — lithium or lead
- Controller
Cabin
Two benches, two lockers.
Each bench is 600 mm long at a seat height of 760 mm, and each one is the lid of a locker. 51 L between them.
- 51 L across two decks
- 760 mm seat height
Rear axle
Sprung, and braked.
A spring adjustable shock over the rear axle, a drum brake on it, and the same 3.00 - 8 tubeless tyre as the front.
- Drum brake
- 3.00 - 8 tubeless
08Assembly
Then back together.
Six stations, one drawing. Scroll to build the NJA-8 — or pick a station.
0/6Parts on the floor
The ladder frame everything bolts to — rated for 250 Kg of people and cargo.
09Standing still
Four of the things the NJA-8 is fitted with have nothing to do with riding it. They are for the hours it spends somewhere you are not.
Anti-theft alert system
It raises an alert if the vehicle is interfered with while you are somewhere else.
Electronic wheel-movement lock
The wheel is held electronically, so moving the vehicle is not simply a matter of pushing it.
Remote operation
Handled from the remote rather than from the vehicle itself.
Parking mode
A mode for standing still, kept separate from the ones for moving.
Fitted as standard, and listed in full on the sheet below.
10Specification · NJA-8
Motor
- Motor Type
- BLDC Mid Motor
Battery
- Battery Type
- Lithium / Lead
- Range / Mileage
- 70 km
Charger
- Full Charging Time
- 4:30 hr (Lithium) / 10:00 hr (Lead)
Brakes
- Front Brake Type
- Drum Brake
- Rear Brake Type
- Drum Brake
Suspension
- Front Suspension
- Telescopic Shock Absorber
- Rear Suspension
- Spring Adjustable Shock
Wheels & Tyres
- Wheel Type
- Tube Less
- Front Wheel Tyre
- 3.00 - 8
- Rear Wheel Tyre
- 3.00 - 8
Vehicle
- Max Load Capacity (inc. passengers & cargo)
- 250 kg
- Ground Clearance
- 140 mm
- Overall Length
- 1950 mm
- Overall Width
- 690 mm
- Overall Height
- 1190 mm
Seat
- Seat Height
- 760 mm
- Seat Length
- 600 mm
- Boot Space
- 51 L
Features
- Reverse Mode
- Yes
- Remote Operation
- Yes
- All Lamp
- LED
- Head Light Lamp
- LED Projector
- Electronic Wheel-Movement Lock
- Yes
- Parking Mode
- Yes
- Anti-Theft Alert System
- Yes
Figures as supplied on the NJA-8 specification sheet. Range and charging time vary with load, terrain, riding style and battery condition.
11Configure
The NJA-8 is one vehicle. What changes is the battery in it — how far it goes, how long it takes to fill, and how long it is covered for.
Starting price
₹1,03,729Lithium · ex-showroom
Choose your battery5 available
Prices are ex-showroom and exclude insurance, registration and accessories.
12Take it out
Book a free test ride at a GOEEN showroom, or find the dealer nearest you. No pressure — the road, the throttle and your own verdict.
- Range
- 70 km
- Load capacity
- 250 Kg
- Motor
- BLDC Mid Motor
- Charging
- 4:30 hr (Lithium) / 10:00 hr (Lead)
- Head lamp
- LED Projector
